100G QSFP28 1310nm ER4 utilizes four-channel LAN WDM wavelength division multiplexing technology to convert four 25Gbps electrical signals into optical signals. After multiplexing, the signals are transmitted over a single LC duplex SMF achieving a transmission distance of 40km.
Specification
Number：CL100GQSFPER4
Vendor:C-LIGHT
Form Factor:QSFP28
Data Rate Max：103.125Gbps (4x 25.78Gbps)
Wavelength：1310nm
Distance：40km
Connector：LC
Media：SMF
Transmitter Type：4 x LAN WDM EML
Receiver Type：PIN
TX Power：-2dBm~5dBm
Receiver Sensitivity：< 21dbm
Power Budget：19dBm
Receiver Overload：< -4.5dBm
Power Consumption：≤5.5W
Extinction Ratio：>8dB
DDM/DOM：Supported
Industrial Temperature Range：0 to 70°C
CDR：TX & RX Built-in CDR
Protocols：SFF-8661 Rev 2.5, SFF-8636 Rev 2.10a,QSFP28 MSA and IEEE 802.3bm-2015
Warranty：3 Years
